IMA Labeling at Interpack 2026
At Interpack 2026, IMA Labeling turns labeling into a strategic lever for performance and integration within the massive IMA Group Hall 17 hub.
Electro-pneumatic swing applicator
FlexiMate eSwing is a modular print & apply solution designed to handle labeling applications where flexibility and accessibility make the difference.
Its programmable electric swing arm enables precise positioning across multiple angles, allowing accurate label application on moving products even in complex production layouts.
With full control over motion parameters, the system ensures smooth, repeatable performance while reducing mechanical stress and improving overall reliability.
The modular design allows easy configuration for different applications, including multi-side labeling, adapting seamlessly to evolving production needs.
Designed for flexible front-side labeling, FlexiMate eSwing is a modular print & apply solution based on a programmable swing arm.
Its electric motion enables precise and controlled positioning across a wide range of angles, adapting seamlessly to different products and production layouts.
Highlights
Highlights
Programmable swing motion allows positioning from 0° to 180°. Adapting easily to different application angles and production layouts.
Highlights
Electric actuation ensures smooth, controlled motion with fully adjustable acceleration and deceleration. Enhancing application precision while minimizing mechanical stress and wear.
Highlights
Designed for front-side labeling on moving products, even in dynamic production environments. Ensuring reliable performance across a wide range of applications.
Highlights
Capable of printing and applying two labels on adjacent sides in real time. Increasing efficiency and reducing cycle time in multi-side labeling applications.
| FlexiMate eSwing | 4″ Liner / 6″ Liner |
| Available versions | Right or left |
| Typical application | On moving or static products |
| Methods of application | Tamp & Blow (no contact) |
| Side of application | Front 2 sides Back |
| Nominal stroke of the applicator unit | 250 mm 400 mm |
| Stroke type | Fixed Programmable Variable with proximity sensor |
| Tamp pad coupling system | Fixed |
| Maximum tamp pad size (W x H) | 120 x 90 mm 120 x 160 mm 160 x 123 mm |
| Accuracy of application | +/- 1 mm typical |
| Unwinding capacity | Ø up to 350 mm |
| Frequency of application | Up to 40 cycles/min |
| Ambient temperature | 5 – 35 °C |
| Environmental conditions | 20 – 90 % relative humidity with no condensation |
| Protection class | IP 2X |
| User interface | 800 x 480 px touch screen display control panel |
| Service interface | LinkMate (on PC) |
| Standard connectors | M12 display connector M12 low paper sensor connector M12 primary product sensor connector M12 secondary product sensor connector M12 beacon light connector USB connector DB9 applicator unit connector DB15 print engine connector DB25 I/O interface connector |
| Optional connectors | Ethernet connector |
